Introduction:

Coupling installation and debugging, in order to perfect. The concentricity of two axes and the precision of shaft holes are very important. All kinds of couplings have a clear national standard for coupling installation and debugging requirements, which is a guiding document for the design and manufacture of coupling manufacturers, but also a technical guidance document for coupling users to install and debug. Coupling quality manufactured by coupling manufacturers is the key to the stability of the transmission system, and coupling installation and debugging is also the embodiment of the stability of the transmission system and coupling quality.

Installation of different couplings:

For example, the installation and debugging of TMG diaphragm coupling, because it is suitable for medium and high speed stable load transmission system, the torque transfer of diaphragm coupling is realized by metal flexible components, therefore, the concentricity requirement of both ends of the transmission shaft is very high, and at the same time, the concentricity of both ends of the two halves of the coupling hole and the two ends of the transmission shaft matching tolerance is also quite critical. Some coupling users in order to disassemble the coupling is convenient, the coupling manufacturers are required to increase the tolerance of the coupling hole (so that the shaft and the coupling to match the gap), and take fastening bolts fastening, so that the coupling in the transmission system at high speed will produce trace vibration, and then make the coupling stability at the same time, Early failure of coupling fittings (diaphragm and connecting bolt). The same is true for the installation and debugging of the drum gear coupling. In particular, coupling manufacturers of drum gear coupling most of the coupling installation is to take the vertical installation state, and the actual coupling user in the installation of a lot of horizontal position installation, at this time, it is necessary to pay attention to the clearance problem of the coupling inner gear ring and coupling outer gear sleeve, to ensure the radial clearance uniform state of horizontal movement of the inner gear ring, Do not knock the inner gear ring in the state of uneven radial clearance (easy to produce internal and external teeth bite).

To sum up:

All kinds of coupling installation and debugging, are in strict accordance with the provisions of the national standards, coupling manufacturers of high quality manufacturing of the coupling is very important, coupling user installation and debugging will affect the quality of the coupling.
